Description:
ESP8266 ESP-01 ESP01 ESP-01S Serial WiFi Wireless Adapter Module 3.3V 5V Serial Board For Microcontroller
A adapter module for ESP-01 ESP-01S Wi-Fi module. 3.3V voltage regulator circuit and onboard level conversion circuit can make 5V microcontroller easy to use with ESP-01 Wi-Fi module.
Also, the item can be used with For Arduino UNO R3 or compatible board.
Specification :
- Processor: The ESP-01 module is powered by the ESP8266 chip, which has a 32-bit Tensilica Xtensa LX106 RISC processor.
- Clock Frequency: The ESP-01 module has a clock frequency of 80 MHz.
- Flash Memory: The ESP-01 module has 1 MB of flash memory, which can be used to store the program and data.
- RAM: The ESP-01 module has 80 KB of RAM, which can be used to store variables and data during runtime.
- Wi-Fi: The ESP-01 module has built-in Wi-Fi connectivity with support for 802.11 b/g/n protocols.
- Serial Interface: The ESP-01 module has a serial interface that can be used to communicate with other devices. It supports a baud rate of up to 115200.
- GPIO Pins: The ESP-01 module has 2 GPIO pins, which can be used for input/output, PWM, and interrupt functions.
- Operating Voltage: The ESP-01 module operates on a voltage range of 3.3V to 3.6V DC.
- Operating Current: The ESP-01 module requires a maximum operating current of 170 mA.
- Programming Language: The ESP-01 module can be programmed using the Arduino IDE with the ESP8266 core or Lua language.
- Dimensions: The ESP-01 module has dimensions of 24mm x 14.5mm x 3mm.
