Description:
This mini OLED display module is equipped with SSD1306 chipset and 128X64 white color display. On-board standard IIC and SPI dual serial connunication interface enable you to connect it with the MCU development board more easily to develop your OLED display projects.
Specifications:
- Screen Display Size: 0.96"
- Display Resolution: 128X64 pixel
- Driver IC:SSD1306
- Display Color: Yellow&Blue
- Communication Interface:IIC and SPI
- Working Voltage: DC 2.8-5.5V
Features:
- Color: Blue and Yellow
- Resolution: 128x64
- Power: 0.06W
- Wide power supply range: DC 3V-5V
- Temperature: -30°C to 70°C
- Dimension: 29.28 x 27.1 mm (LW)
- Compatible with 3.3V and 5V control chip I / O level
- OLED internal drive chip: SSD136
